HPM HPM200 Drill Rig, New Equipment, 275 hp, 120 ft D Drill, 8 ft Dia Drilling

Manufacturer: HPM ITALY
Brand: HPM
Item Number: 200
MPN: HPM200
CPN:
Model #: HPM200
    • Add-On Options Available      :      Auxiliary Swing Brake, Biodegradable Hydraulic Oil, Pre-Disposition Casing Oscillator, Central Lubrication System, CFA Kit, Low Headroom Kit, Remote Control, Self-Erecting Counterweight, Universal Casing Joint, Walking Platform, Winch Crowd System
    Auxiliary Winch Capacity      :      26000 lb
    Base Machine Model      :      330
    Condition      :      New
    Control Type      :      Remote
    Crowd Push/Pull Force      :      70000 lb
    Crowd Stroke      :      14 ft 6 in
    Crowd Type      :      Cylinder
    Dimensions      :      54 ft 10 in L x 9 ft 10 in W x 11 ft 6 in H
    Discharge Speed      :      50 to 120 rpm
    Divisions      :      BLAZE
    Drilling Depth      :      120 ft
    Drilling Diameter      :      8 ft
    Engine Displacement      :      428 cu-in
    Engine Horsepower      :      275 hp
    Engine Manufacturer      :      CAT®
    Fuel Tank Capacity      :      125.2 gal
    Fuel Type      :      Diesel
    Main Winch Capacity      :      51700 lb
    Mast Configuration      :      Standard
    Model      :      200
    Operating Weight      :      128300 lb
    Rotary Effective Torque      :      185000 ft-lb
    Rotary Nominal Torque      :      217500 ft-lb
    Standard Kelly Bar      :      4/120
    Undercarriage Type      :      Track
    Working Speed      :      9 to 24 rpm

    Correct, we don't think there is much to add. But since we have to fill the page we will also say that it's modulr design allow you to convert this rig in different configurations, including short mast - 11' version. The great stability offered by the expandable undercarriage will also allow to customize the rig in order to install a Crowd Winch System, also suitable for CFA.

    HPM Drill Rig, Model: 200, New Condition, Base Machine Model: 330, 275 hp Engine Horsepower, CAT® Engine Manufacturer, 428 cu-in Engine Displacement, Standard Mast Configuration, 217500 ft-lb Rotary Nominal Torque, 185000 ft-lb Rotary Effective Torque, 9 to 24 rpm Working Speed, 50 to 120 rpm Discharge Speed, 120 ft Drilling Depth, 8 ft Drilling Diameter, 51700 lb Main Winch Capacity, 26000 lb Auxiliary Winch Capacity, Cylinder Crowd, 70000 lb Crowd Push/Pull Force, 14 ft 6 in Crowd Stroke, 128300 lb Operating Weight, 4/120 Standard Kelly Bar, Diesel Fuel, 125.2 gal Fuel Tank Capacity, Track Undercarriage, Remote Control, Add-On Options Available: Auxiliary Swing Brake, Biodegradable Hydraulic Oil, Pre-Disposition Casing Oscillator, Central Lubrication System, CFA Kit, Low Headroom Kit, Remote Control, Self-Erecting Counterweight, Universal Casing Joint, Walking Platform, Winch Crowd System, 54 ft 10 in L x 9 ft 10 in W x 11 ft 6 in H

      Remote Control - Increase safety and flexibility when loading or unloading the equipment. The operator can make use of different viewing angles while moving the machine from outside the cabin. Having a complete view of the rig during these phases allows the operator to make sure that hoses, wirings and wire ropes are safely positioned. Drilling functions are enabled through the remote control for a safe service and maintenance of the rig
