Elliott HiReach™ L115 Aerial Work Platform, New Equipment, End-Hung, Rotating Platform, Wheeled

Manufacturer: Elliott Equipment Company
Brand: Elliott
Item Number: L115
MPN: L115
CPN:
Model #: L115
  • Heavy This item has special delivery requirements Please contact Owen Companies to order
    • Rental AVAILABLE
    Add-On Options Available      :      Bed Accessory, Boom-Mounted Winch, Custom Paint, Ergonomic Ride-Around Seated Control, Extended Truck Cab, Outrigger Pad Holder, Rear Bumper
    Additional Information      :      14000 lb Main Winch Capacity, 60000 lb Recommended GVWR
    Condition      :      New
    Dimensions      :      483 in L x 12 ft 6 in H
    Lift Mechanism      :      Telescopic Boom
    Maximum Horizontal Reach      :      80 ft
    Maximum Working Height      :      115 ft
    Mobility Type      :      Wheeled
    Model      :      L115
    Number of Occupants      :      2
    Number of Sections      :      5
    Outrigger Spread      :      20 ft
    Outrigger Type      :      Out-Down
    Platform Height      :      135 ft
    Platform Load Capacity      :      600 lb
    Platform Size      :      30 x 54 in
    Platform Type      :      End-Hung, Rotating
    Weight      :      30400 lb

    When crews need height, reach, and real productivity from one truck, the Elliott L115 HiReach delivers. Mounted on a tandem-axle chassis for stability and payload, the L115 pairs 115 ft working height with wide side reach, material handling on the main boom and in the platform, and Elliott's field-proven reliability. It's built to help teams do more with a single machine - from utility construction to lighting maintenance and complex installs.

    Elliott HiReach™ Aerial Work Platform, Model: L115, New Condition, End-Hung, Rotating Platform, 115 ft Maximum Working Height, 30 x 54 in Platform, 135 ft Platform Height, 80 ft Maximum Horizontal Reach, 600 lb Platform Load Capacity, 2 Occupants, Telescopic Boom Lift Mechanism, 5 Sections, Out-Down Outrigger, 20 ft Outrigger Spread, Wheeled Mobility, Add-On Options Available: Bed Accessory, Boom-Mounted Winch, Custom Paint, Ergonomic Ride-Around Seated Control, Extended Truck Cab, Outrigger Pad Holder, Rear Bumper, 483 in L x 12 ft 6 in H, 30400 lb Weight, Additional Information: 14000 lb Main Winch Capacity, 60000 lb Recommended GVWR

    • MORE ROOM, MORE WORK DONE - A 30″ x 54″ platform comfortably fits two workers plus tools, improving job site efficiency and reducing trips up and down
    • END-MOUNT ROTATING PLATFORM - The end-hung, rotating platform keeps you oriented to the work face for faster placements and less truck repositioning
    • WIDE SIDE REACH + ZERO TAILSWING - Cover more area per setup with long horizontal reach and zero tailswing - ideal for roadside lanes, ramps, terminals, and tight urban sites
    • PERSONNEL + MATERIAL HANDLING - Built-in material handling at the main boom and in-platform lifting lets one truck tackle install, service, and replacement tasks - higher utilization, lower total cost of ownership
    • 180 deg PLATFORM ROTATION - Access challenging angles without moving the truck - boosting safety and speed on high or offset work
    • "OFFICE IN THE SKY" PRODUCTIVITY - Optional power/air, tool circuits, lighting, storage, and communications turn the platform into a high-efficiency workstation
    • INDUSTRY-LEADING COVERAGE - Backed by a one-year parts & labor warranty and lifetime structural warranty - confidence for the life of your machine
