| Add-On Options Available | : | Auger Tool, Custom Line Body and Flat Bed, Front Recovery Winch, Hydraulic Tool Outlet and Reel, Radio Anti-Two Block |
| Additional Information | : | 38 ft Maximum Horizontal Reach, 360 deg Boom Rotation |
| Auger Speed | : | 80 rpm |
| Auger Torque Rating | : | 12000 ft-lb |
| Condition | : | New |
| Control Type | : | Hydraulic |
| GVWR (Gross Vehicle Weight Rating) | : | 33000 lb |
| Main Winch Pull | : | 12000 lb |
| Maximum Digging Radius | : | 26 ft |
| Maximum Lifting Capacity | : | 26000 lb |
| Maximum Sheave Height | : | 47 ft |
| Model | : | D47i |
| Outrigger Spread | : | 13 ft 11 in |
| Outrigger Type | : | Type A Frame |
| Retracted Sheave Height | : | 30 ft |
The D47 puts you in command with full-pressure hydraulic controls, outstanding operator comfort, and the smooth, responsive performance you need to work efficiently and confidently - job after job.
Elliott Digger Derrick, Model: D47i, New Condition, 26000 lb Maximum Lifting Capacity, 47 ft Maximum Sheave Height, 30 ft Retracted Sheave Height, 12000 ft-lb Auger Torque Rating, 80 rpm Auger Speed, 26 ft Maximum Digging Radius, 33000 lb GVWR, Type A Frame Outrigger, 13 ft 11 in Outrigger Spread, 12000 lb Main Winch Pull, Hydraulic Control, Add-On Options Available: Auger Tool, Custom Line Body and Flat Bed, Front Recovery Winch, Hydraulic Tool Outlet and Reel, Radio Anti-Two Block, Additional Information: 38 ft Maximum Horizontal Reach, 360 deg Boom Rotation
- Best in Class Lifting Capacity - With a maximum lifting capacity of 26,000 lb and 11,500 lb at a 10‑ft radius, the D47i offers unmatched strength in its class. This lets crews handle the heaviest poles and materials with confidence, minimizing the need for support equipment
- Full Pressure Open Center Hydraulics - The full‑pressure, open‑center hydraulic system delivers consistent power flow and fast, responsive control across all derrick functions. Operators benefit from smoother digging and lifting operations, reducing fatigue and cycle time
- Premium Planetary Swing Drive & Winch Motor - Equipped with high‑performance planetary swing drive and winch motor - features usually seen on larger machines - the D47i ensures precise, reliable loading and positioning. This enhances operational efficiency, especially in tight or sensitive work zones
- Ergonomic Control Console With Air Suspension Seat - The ergonomically designed console and high‑back air‑suspension seat significantly reduce operator strain during long shifts. This creates a more comfortable and fatigue‑resistant work environment that improves productivity
- Dual Lift Cylinders - Dual lift cylinders offer enhanced lifting stability and better load control under heavy loads. This provides smoother operation when raising or lowering poles, reducing jolt and sway
- Hydraulic Side Load Protection - The built‑in side-load protection system guards against dangerous off‑axis stresses, prolonging boom life and improving safety. It provides peace of mind to operators working under varied angles or tough conditions
- Radio Anti-Two-Block - The integrated radio anti‑two‑block safety system prevents the hook from contacting the boom tip, eliminating a common and costly hazard. Wired into the machine, it ensures reliable, electromagnetic-free protection in high-voltage work areas
- 46kV Insulating - The fully 46 kV rated insulated boom and components allow safe operation around energized high-voltage lines. This capability is essential for power distribution and utility tasks near live circuits
- Backed By Lifetime Structural Warranty - Elliott's lifetime structural warranty on the D47i covers the backbone of the machine, reducing owner risk and maintenance costs. It ensures long-term value retention and confidence in the equipment's durability
- ANSI A10.31 Compliant - Fully compliant with ANSI A10.31 safety standards for digger derricks, the D47i meets or exceeds industry regulations. This compliance supports responsible operations and helps avoid regulatory issues on the job
