CMC 90HD+ Arbor Pro Aerial Lift, New Equipment, 90 ft Max Working Height, 83 ft H Platform, Diesel
Manufacturer: CMC North America
Brand: CMC
Item Number: 90HD+ Arbor Pro
MPN: 90HD+ Arbor Pro
CPN:
Model #: 90HD+ Arbor Pro
This item has special delivery requirements
Please contact Owen Companies to order
Rental AVAILABLE
| Additional Information | : | 507 lb Maximum Basket Load Capacity, +/-90 deg Jib Articulation |
| Condition | : | New |
| Dimensions | : | 22 ft 4 in L x 55 in to 11 ft 11 in W x 86 in H |
| Engine Manufacturer | : | Kubota |
| Fuel Type | : | Diesel |
| Lift Mechanism | : | Boom |
| Maximum Horizontal Reach | : | 50 ft |
| Maximum Working Height | : | 90 ft |
| Mobility Type | : | Track |
| Model | : | 90HD+ Arbor Pro |
| Platform Extension Length | : | 50 ft 6 in |
| Platform Height | : | 83 ft |
| Power Source | : | Diesel |
| Travel Speed | : | 0 to 2.2 fps |
| Weight | : | 9058 lb |
CMC Aerial Lift, Model: 90HD+ Arbor Pro, New Condition, Kubota Engine Manufacturer, Diesel, Diesel Fuel, 90 ft Maximum Working Height, 83 ft Platform Height, 50 ft Maximum Horizontal Reach, 50 ft 6 in Platform Extension Length, Boom Lift Mechanism, Track Mobility, 0 to 2.2 fps Travel Speed, 22 ft 4 in L x 55 in to 11 ft 11 in W x 86 in H, 9058 lb Weight, Additional Information: 507 lb Maximum Basket Load Capacity, +/-90 deg Jib Articulation
- Radio remote control to operate all functions with LED display and on-board diagnostics
- Fixed platform control station
- Double telescopic upper boom
- New upper and lower boom designs provide more working height and lateral outreach
- +/-90 deg Articulating jib
- Single-man fiberglass basket with quick connect bracket
- Articulating upper and lower booms
- Telescopic lower boom
- Kubota 3-cylinder D902 diesel engine
- Automatic chassis self-leveling
- Remote technical assistancel
- +/-400 deg Rotating rear mounted turret
- Vertically/horizontally independent adjustable tracks with up to 15" of ground clearance
