Bandit 3590

Bandit 3590 Drum-Style Chipper, New Equipment, 755 to 1050 hp, Diesel Fuel, 30 in Dia Log

Manufacturer: Bandit Industries, Inc
Brand: Bandit
Item Number: 3590
MPN: 3590
CPN:
Model #: 3590
  • Add-On Options Available      :      Vertical Side Feed Wheel
    Axle Capacity      :      25000 lb
    Brake Type      :      Air
    Condition      :      New
    Control Type      :      Remote
    Dimensions      :      504 in L x 140 in W x 158 in H
    Discharge Type      :      Forestry Style Stationary
    Divisions      :      CAL_LINE
    Drum Diameter      :      37 in
    Drum Width      :      48 in
    Engine Horsepower      :      755 to 1050 hp
    Engine Manufacturer      :      CAT®
    Feed Rate      :      120 fpm
    Feed System Type      :      Slide Box
    Feed Type      :      Whole Tree
    Feed Wheel Diameter      :      15-3/4 in Top, 10-5/8 in Bottom
    Feed Wheel Width      :      48 in
    Fuel Tank Capacity      :      200 gal
    Fuel Type      :      Diesel
    Hydraulic Tank Capacity      :      350 gal
    Knife Count      :      8
    Knife Size      :      12-1/8 in L x 6 in W x 5/8 in THK
    Machine Weight      :      64000 lb
    Maximum Log Diameter      :      30 in
    Mobility Type      :      Towable
    Model      :      3590
    Number of Axle      :      2
    Number of Tires      :      8
    Paint Color      :      Bandit Yellow|Green
    Tire Size      :      11 R22.5
    Undercarriage Type      :      Rubber Tire

    The 30-inch capacity Model 3590 is a powerhouse for logging professionals seeking a high-production, low maintenance whole tree chipper. Featuring a 30-inch by 48-inch chipper throat opening and a powerful three wheel feed system, the Model 3590 easily handles large material. This powerful chipper can fill a 45-foot trailer in approximately 12 minutes, consistently outpacing other 30-inch capacity chippers while burning less fuel per load. Engine options ranging from 755 to 1,050 horsepower are available to choose from. The standard forestry style stationary discharge chute enhances chipping throwing velocity, ensuring chip vans are packed to their max capacity.

    Bandit Drum-Style Chipper, Model: 3590, New Condition, 755 to 1050 hp Engine Horsepower, CAT® Engine Manufacturer, 30 in Maximum Log Diameter, 37 in Drum Diameter, 48 in Drum Width, Diesel Fuel, 200 gal Fuel Tank Capacity, 350 gal Hydraulic Tank Capacity, 8 Knife Count, 12-1/8 in L x 6 in W x 5/8 in THK Knife Size, Whole Tree Feed, Slide Box Feed System, 120 fpm Feed Rate, 15-3/4 in Top, 10-5/8 in Bottom Feed Wheel Diameter, 48 in Feed Wheel Width, Forestry Style Stationary Discharge, Towable Mobility, Rubber Tire Undercarriage, 25000 lb Axle Capacity, 2 Axle, Air Brake, Remote Control, 11 R22.5 Tire, 8 Tires, Bandit Yellow|Green Paint Color, Add-On Options Available: Vertical Side Feed Wheel, 504 in L x 140 in W x 158 in H, 64000 lb Machine Weight

      37" diameter x 48" wide chipper drum with 8 knives
