Bandit 2590

Bandit 2590 Drum-Style Chipper, New Equipment, 755 to 800 hp, Diesel Fuel, 23 in Dia Log

Manufacturer: Bandit Industries, Inc
Brand: Bandit
Item Number: 2590
MPN: 2590
CPN:
Model #: 2590
  • Add-On Options Available      :      3 in Pintle Ring or Fifth Wheel Hitch, Super Single Tire
    Brake Type      :      Air
    Condition      :      New
    Dimensions      :      31 ft 5 in to 38 ft 5 in L x 9 ft 11 in to 10 ft 2 in W x 11 ft 7 in to 12 ft 8 in H
    Discharge Type      :      Stationary Swivel
    Divisions      :      CAL_LINE
    Drum Diameter      :      37 in
    Drum Width      :      30 in
    Engine Horsepower      :      755 to 800 hp
    Engine Manufacturer      :      CAT®
    Feed Rate      :      120 fpm
    Feed System Type      :      Slide Box
    Feed Type      :      Whole Tree
    Feed Wheel Diameter      :      27 in Top, 10-5/8 in Bottom
    Feed Wheel Width      :      36 in
    Fuel Tank Capacity      :      130 gal
    Fuel Type      :      Diesel
    Hydraulic Tank Capacity      :      85 gal
    Knife Count      :      6
    Knife Size      :      10 in L x 5-1/2 in W x 5/8 in THK
    Machine Weight      :      42000 to 44000 lb
    Maximum Log Diameter      :      23 in
    Mobility Type      :      Towable
    Model      :      2590
    Number of Axle      :      2
    Number of Tires      :      8
    Paint Color      :      Bandit Yellow|Green
    Tire Size      :      10 R17.5
    Undercarriage Type      :      Rubber Tire

    Officially rated as a 23-inch capacity whole tree chipper, the Model 2590 actually has a 26.25-inch by 30-inch chipper throat opening so it easily handles large whole trees, tops, and logging slash. It features Bandit's unique Slide Box Feed System, and is available with a dedicated micro chip drum to be utilized to produce a chip for pellets. A durable 37" diameter x 30" wide drum equipped with six dual edge or babbitted knives. This drum is so rugged it is backed by Bandit's 5-year "GUTS" warranty. Depending on engine options, the Model 2590 can fully load chip trailers in around 16-18 minutes. A standard 7 1/2' infeed conveyor provides further assistance for loading and pulling material into the chipper. Customers can choose from Caterpillar engine options that include a C18, 755 or 800 horsepower engine. The standard forestry style stationary discharge chute enhances chipping throwing velocity fully packing chip vans to their max capacity.

    Bandit Drum-Style Chipper, Model: 2590, New Condition, 755 to 800 hp Engine Horsepower, CAT® Engine Manufacturer, 23 in Maximum Log Diameter, 37 in Drum Diameter, 30 in Drum Width, Diesel Fuel, 130 gal Fuel Tank Capacity, 85 gal Hydraulic Tank Capacity, 6 Knife Count, 10 in L x 5-1/2 in W x 5/8 in THK Knife Size, Whole Tree Feed, Slide Box Feed System, 120 fpm Feed Rate, 27 in Top, 10-5/8 in Bottom Feed Wheel Diameter, 36 in Feed Wheel Width, Stationary Swivel Discharge, Towable Mobility, Rubber Tire Undercarriage, 2 Axle, Air Brake, 10 R17.5 Tire, 8 Tires, Bandit Yellow|Green Paint Color, Add-On Options Available: 3 in Pintle Ring or Fifth Wheel Hitch, Super Single Tire, 31 ft 5 in to 38 ft 5 in L x 9 ft 11 in to 10 ft 2 in W x 11 ft 7 in to 12 ft 8 in H, 42000 to 44000 lb Machine Weight

      (1) 27" diameter x 36" wide top feed wheel (Driven via (2) 63.9 CID motors / chain)
