Bandit 2460XP

Bandit 2460XP Horizontal Grinder, New Equipment, 536 hp, 60 in W x 24 in H Max Feed, 24 in Hopper

Manufacturer: Bandit Industries, Inc
Brand: Bandit
Item Number: 2460XP
MPN: 2460XP
CPN:
Model #: 2460XP
  • Additional Information      :      36 in Dia x 60 in W Cuttermill
    Axle Capacity      :      20000 lb
    Brake Type      :      Air
    Condition      :      New
    Control Type      :      Remote
    Conveyor Length      :      22 ft 9 in
    Dimensions      :      512 in L x 102 in W x 162 in H
    Discharge Height      :      15 ft
    Discharge Type      :      Conveyor
    Divisions      :      CAL_LINE
    Emission Standard      :      Tier 4
    Engine Horsepower      :      536 hp
    Engine Manufacturer      :      CAT®
    Fuel Tank Capacity      :      250 gal
    Fuel Type      :      Diesel
    Hitch Type      :      3 in Pintle
    Hopper Capacity      :      24 in
    Hydraulic Tank Capacity      :      120 gal
    Infeed Opening Height      :      14 ft 8 in
    Infeed Opening Width      :      60 in
    Machine Weight      :      48000 lb
    Maximum Feed Size      :      60 in W x 24 in H
    Mobility Type      :      Towable
    Model      :      2460XP
    Number of Axle      :      2
    Number of Hammers/Teeth      :      30
    Number of Tires      :      4
    Paint Color      :      Bandit Yellow|Green
    Tire Size      :      385/60 R22.5
    Undercarriage Type      :      Towable

    The Beast® Model 2460XP will out perform all other grinders in its size class. The 2460XP is equipped with a 60" wide by 30" diameter cuttermill and a 24" high x 60" wide mill opening. This machine uses a 30-tooth cuttermill running Bandit's saw-tooth style cutterbodies that regulate the size of the tooth's bite. Most of the material is sized in the initial cut, so material exits the large screening area quicker. A Caterpillar C13B, 536 horsepower engine is standard and provides ample torque to grind an array of material. A wide variety of tooth and screen options are available to adequately process and size material. Two screens are equipped behind the mill and can easily be changed by being removed from the side of the machine. The standard height adjustable discharge gives ample room for discharging material and features a magnetic head pulley at the end for separating nails from the mulch pile. A 14' 8" long x 60" infeed with double slat design track style infeed conveyor provides ample room for feeding a wide variety of material. A 20" diameter feed wheel further assists with pulling material into the mill. All grinding functions are controlled with a wireless radio remote control with tether back-up.

    Bandit Horizontal Grinder, Model: 2460XP, New Condition, 536 hp Engine Horsepower, CAT® Engine Manufacturer, Diesel Fuel, 250 gal Fuel Tank Capacity, 120 gal Hydraulic Tank Capacity, 30 Hammers/Teeth, 60 in W x 24 in H Maximum Feed Size, 24 in Hopper Capacity, 14 ft 8 in Infeed Opening Height, 60 in Infeed Opening Width, Conveyor Discharge, 22 ft 9 in Conveyor Length, 15 ft Discharge Height, Towable Mobility, Towable Undercarriage, 20000 lb Axle Capacity, 2 Axle, Air Brake, 385/60 R22.5 Tire, 4 Tires, 3 in Pintle Hitch, Remote Control, Tier 4 Emission Standard, Bandit Yellow|Green Paint Color, 512 in L x 102 in W x 162 in H, 48000 lb Machine Weight, Additional Information: 36 in Dia x 60 in W Cuttermill

      (2) 20,000 pound air brake axles with (4) 385/60R 22.5" tires
