Bandit INTIMIDATOR™ 18XP - Track Drum-Style Chipper, New Equipment, 173 to 174 hp, Diesel Fuel

Manufacturer: Bandit Industries, Inc
Brand: Bandit
Item Number: 18XP - Track
MPN: 18XP - Track
CPN:
Model #: 18XP - Track
  • Add-On Options Available      :      Caterpillar 305CR Rubber or Steel Track Undercarriage, Hydraulic Winch
    Condition      :      New
    Control Type      :      Remote
    Dimensions      :      185 in L x 102 in W x 112 in H
    Discharge Rotation      :      270 deg
    Discharge Type      :      Swivel
    Divisions      :      CAL_LINE
    Drum Diameter      :      37 in
    Drum Width      :      22 in
    Engine Horsepower      :      173 to 174 hp
    Feed Motor Type      :      Hydraulic
    Feed Rate      :      100 fpm
    Feed System Type      :      Slide Box
    Feed Type      :      Hand Feed
    Feed Wheel Diameter      :      10-5/8 in
    Feed Wheel Width      :      20 in
    Fuel Tank Capacity      :      50 gal
    Fuel Type      :      Diesel
    Hydraulic Tank Capacity      :      50 gal
    Machine Weight      :      13500 lb
    Maximum Branch Diameter      :      18 in
    Mobility Type      :      Track
    Model      :      18XP - Track
    Paint Color      :      Bandit Yellow|Green
    Undercarriage Type      :      Rubber Track

    The 18XP track is one of Bandit's more popular machines available on tracks. The large 37" diameter 4-knife drum enhances the 18XP's ability to chip larger diameter material or multiple pieces at one time. John Deere 173 or Caterpillar 174 horsepower diesel engines are and provide ample torque creating an efficient chipping action. The 18XP track features the proven slide box dual feed wheel system designed to effectively pull, compress, and crush material into the chipper. The slide box allows the top feed wheel to travel straight up and down and provides direct down pressure as material enters the feed wheels. Each feed wheel is driven by high displacement hydraulic motor generating an abundant amount of pulling power reducing the need to trim or re-position material. A 305CR Caterpillar rubber track undercarriage enhances durability all while providing a stable travel platform. This undercarriage features a travel speed ranging from 2.3 to 4.1 MPH and has triple grousers for the ultimate flotation and reduced ground pressure. A steel undercarriage is available as an option and is recommended for rocky soil conditions. All track and chipper functions are controlled by a wireless radio remote control with tether back-up.

    Bandit INTIMIDATOR™ Drum-Style Chipper, Model: 18XP - Track, New Condition, 173 to 174 hp Engine Horsepower, 18 in Maximum Branch Diameter, 37 in Drum Diameter, 22 in Drum Width, Diesel Fuel, 50 gal Fuel Tank Capacity, 50 gal Hydraulic Tank Capacity, Hand Feed Feed, Slide Box Feed System, 100 fpm Feed Rate, 10-5/8 in Feed Wheel Diameter, 20 in Feed Wheel Width, Hydraulic Feed Motor, 270 deg Discharge Rotation, Swivel Discharge, Track Mobility, Rubber Track Undercarriage, Remote Control, Bandit Yellow|Green Paint Color, Add-On Options Available: Caterpillar 305CR Rubber or Steel Track Undercarriage, Hydraulic Winch, 185 in L x 102 in W x 112 in H, 13500 lb Machine Weight

      Caterpillar 174 or John Deere 173 horsepower engine options
